Key features
- Unique Plasma Emission Detector design based on a Duty Cycle Controlled System.
- Integrated oscillation system for drift removal and quick response time
- Response time lower than 30 seconds
- Bootloader integrated for software update via Ethernet
- LAN/Web control
- Touchscreen 7 inches HDMI TFT display
- 4-20 mA output as standard
- Range Identification Relay
- Micro-valve for very low dead volume and fast purging time.
- 3U cabinet
Overview
The LD8001+Ar is designed for ultra-pure Helium gas analysis. With its integrated ppt/ppb oscillation PED module, unique performance can be achieved. Low ppt ultra-fast analysis for online trace argon in UHP helium is now possible without the need of a gas chromatograph. This compact design makes it very attractive for particularly the semiconductor market. The unit is built with a zero-gas generator that combines a heated absorbent with a cryogenic absorbent to completely removes the interferences from other impurities including argon to ensure an accurate calibration/reference.
